KSEY / KSEYK - self-priming, gas-carrying side channel pump in ring-section design

  • Painted KSEY side channel pump in typical Apollo blue color as a complete unit with motor, touch guard, and base plate.

    Bild01 - KSEY

  • Overall view of a KSEY Apollo self-priming side channel pump, compact design with horizontal shaft arrangement and suction and discharge nozzles facing upwards.

    Bild02 - KSEYK

  • On the workshop table stands a self-priming side channel pump from Apollo's KSEY series, which has been assembled and finished with polished metal surfaces. The production hall with workshop accessories can be seen in the background.

    KSEYK

KSEY

Horizontal, self-priming side-channel pump with the ability to pump gas together with the liquid, sectional casing design. The series is marked by compact construction and good suction characteristics.

KSEYK

The suction side is without shaft sealing and with liquid lubricated sliding bearing. Preferably suited for difficult suction conditions.

Operation limits KSEY / KSEYK

Q (m³/h) 20
H (m) 160
P (bar) 16
T (° C) + 120

Application Industries

A white symbolic image with a power plant and smokestack represents energy generation. The background is blue.
A white symbolic image with a drop of water and wavy lines represents the water industry. The background is blue.
A blue symbol with a chemical compound represents the chemical industry.
A blue symbol image with factories symbolises general industry.

Side channel pumps of the KSEY series are used for pumping clean, neutral and combustible liquids without abrasives:

  • water, condensate
  • solvents, fuel
  • oil
  • acids, lyes
  • hydrocarbon
KSEY: Side channel pump with characteristic curve field for pressure and performance characteristics.
KSEY - characteristic curve
  • according to Apollo standard
  • horizontal, self-priming side-channel pump with the ability to pump gas together with the liquid, sectional casing design
  • compact design
  • good suction behaviour
  • suction and discharge branches are positioned radially vertically to the top
  • oval flange version PN10,  counter flanges with internal thread (single-stage and 2-stage versions)
  • round flange version PN16, connection dimensions according to DIN EN 1092-1  (3-stage and multistage versions)
  • two external grease lubricated grooved ball bearings for most hard application conditions
  • versions with stuffing box or mechanical seal
  • grey cast iron
  • ductile iron
  • stainless steel
